Multi-Purpose Low Speed Centrifuge (DM0636)

WhatsApp Order

The Multi-Purpose Low Speed Centrifuge (DM0636) is a high-capacity benchtop centrifuge designed for large-volume clinical diagnostic sample processing, blood component separation, urinalysis, molecular biology applications, and industrial laboratory use . Operating at speeds from 300 to 6,000 rpm (up to 4,100 × g) with a maintenance-free brushless DC motor, this centrifuge provides the throughput and versatility needed for high-volume clinical laboratories while maintaining low-speed operation optimal for serum and plasma preparation .

The centrifuge accommodates a wide range of rotors, including swing-out rotors for 4 × 100 mL tubes, fixed-angle rotors for 6 × 50 mL or 30–60 × 2.0 mL tubes, and specialized rotors for microplates and PCR strips . The LCD display allows precise monitoring and adjustment of speed (300-6,000 rpm, increment: 10 rpm) and run time (30 seconds to 99 minutes), with speed/RCF switchover for user convenience . The Pulse key enables instantaneous centrifugation for quick spin-down needs .

For the medical technologist and clinical laboratory scientist, the DM0636 facilitates serum and plasma separation for blood chemistry testing (liver function tests, renal function tests, electrolytes, glucose, lipid profiles), coagulation studies, and routine hematology workflows. It supports urinalysis sediment preparation for microscopic examination, cerebrospinal fluid cell concentration for neurological diagnostic testing, blood bank compatibility testing for transfusion medicine, nucleic acid extraction for molecular diagnostics, and microplate processing for high-throughput screening.

The centrifuge features comprehensive safety protections including door interlock, imbalance protection alarm, over-speed detection, over-temperature detection, and automatic internal diagnosis system . With 9 programmable acceleration and 10 deceleration levels, 9 program memory storage, dynamic balancing for stable operation, and compliance with IEC/EN61010 safety standards, the DM0636 provides reliable, high-throughput performance for routine laboratory workflows supporting patient diagnosis and treatment monitoring .

Compare

Add to wishlist

Categories: LABORATORY EQUIPMENT AND SUPPLIES, Centrifuges and Separators Tags: Benchtop Clinical Centrifuge, Blood Separation, Clinical Laboratory Equipment, DLAB Centrifuge, DM0636 Multi-Purpose Low Speed Centrifuge, High Capacity Centrifuge, IVD Centrifuge, Low Speed Centrifuge, Serum Separation, Urinalysis

Description

Multi-Purpose Low Speed Centrifuge (DM0636)

PRIMARY CLINICAL & DIAGNOSTIC USES

1. Large-Capacity Blood Component Separation for High-Volume Clinical Diagnostics

Primary Use: Provides a high-capacity benchtop low speed centrifuge with a maximum capacity of 4 × 100 mL (swing-out rotor) and options for 6 × 50 mL or 30–60 × 2.0 mL tubes, enabling large-volume separation of whole blood into serum, plasma, and cellular components for diagnostic laboratory analysis .
How it helps: For the medical technologist and clinical laboratory scientist, the DM0636 significantly increases sample processing throughput with its large volume capacity—handling up to four 100 mL tubes or multiple blood collection tubes simultaneously, reducing hands-on time, accelerating turnaround for test results, and improving laboratory efficiency in high-volume clinical settings. For the patient, faster high-volume sample processing means receiving diagnostic results more quickly, enabling earlier diagnosis and treatment initiation.

2. Versatile Centrifugation for Multiple Clinical Applications

Primary Use: Accepts a wide range of optional rotors (fixed angle and swing-out), including rotors for 100 mL, 50 mL, 15 mL, 2.0 mL tubes, microplates, and PCR strips, supporting diverse applications from routine blood work to specialized research protocols .
How it helps: For the laboratory manager, the extensive rotor compatibility eliminates the need for several dedicated centrifuges—allowing a single instrument to handle blood tube processing, urine concentration, plate-based assays, and specialized molecular biology applications. For the patient, versatile equipment ensures that diagnostic testing can be performed efficiently across multiple test types without equipment delays.

3. Serum and Plasma Preparation for Clinical Chemistry

Primary Use: Supports serum and plasma preparation for standard blood chemistry panels including liver function tests, renal function tests, electrolytes, glucose, and lipid profiles using standard vacutainer tubes and tube adapters .
How it helps: For the clinical chemist, the DM0636’s consistent low speed operation (300-6,000 rpm) with ±20 rpm speed accuracy ensures optimal separation of serum and plasma without hemolysis or cellular damage—improving the accuracy of routine chemistry testing. For the patient, high-quality sample preparation reduces the need for repeat blood draws and ensures reliable diagnostic results for common health screenings.

4. Urinalysis and Body Fluid Sediment Preparation

Primary Use: Accommodates urine tubes and conical tubes for urine sediment preparation, as well as cerebrospinal fluid and other body fluid samples for microscopic examination .
How it helps: For the clinical laboratory scientist, the DM0636’s low speed, gentle centrifugation preserves cellular morphology while effectively concentrating sediment elements—improving microscopic diagnostic accuracy for urinary tract infections, kidney disease, and neurological conditions. For the patient, accurate sediment preparation supports correct diagnosis of conditions requiring urinalysis and body fluid testing.

SECONDARY & SUPPORTIVE USES

1. Blood Chemistry and Coagulation Testing Preparation: Used for serum and plasma separation for routine blood chemistry analysis and coagulation studies.

2. Lipoprotein and Lipid Panel Analysis: Supports sample preparation for lipid profiling and cholesterol fractionation for cardiovascular risk assessment.

3. Nucleic Acid Extraction and Purification: Used in DNA and RNA extraction protocols for spin column-based purification in molecular diagnostics.

4. PCR Sample Preparation: Supports spin-down of PCR microtubes and PCR strips for molecular testing workflows.

5. Urinalysis Sediment Preparation: Used for concentration of urine sediment for microscopic examination and culture preparation.

6. Cerebrospinal Fluid (CSF) Processing: Used for cell concentration and sediment preparation for CSF analysis in neurology diagnostics.

7. Pleural, Peritoneal, and Synovial Fluid Analysis: Supports cell concentration and sediment preparation for body fluid cytology and chemistry.

8. Blood Bank and Transfusion Medicine: Used for cross-matching, antibody screening, and blood component preparation.

9. Quality Control Sample Preparation: Supports preparation of QC samples for clinical laboratory quality assurance programs.

10. Aliquot Preparation: Used for preparing sample aliquots for secondary testing, storage, and reference laboratory send-outs.

11. Microplate and Deep-Well Plate Processing: Supports centrifugation of 96-well microplates and deep-well plates for high-throughput screening and sample preparation.

12. Cell Culture and Tissue Homogenate Processing: Used for pelleting cells from culture media and removing cellular debris from tissue homogenates.

13. Basic Research and Academic Laboratories: Used in university and research laboratory settings for routine centrifugation needs.

14. Veterinary Diagnostic Laboratory: Supports sample processing for animal health testing and veterinary diagnostics.

15. Environmental and Food Testing: Used in water quality and food safety laboratories for the separation of particulates from liquid samples.

KEY PRODUCT FEATURES

1. BASIC IDENTIFICATION ATTRIBUTES

Device Type: A large-capacity, multi-purpose benchtop low speed centrifuge designed for clinical diagnostic sample processing, blood component separation, urinalysis, molecular biology applications, and industrial laboratory use .
Designation: DM0636 Multi-Purpose Low Speed Centrifuge, Low Speed Centrifuge, High Capacity Centrifuge, Benchtop Clinical Centrifuge, Multi-Purpose Centrifuge, DLAB DM0636, Laboratory Centrifuge .
Key Components:
- Multiple Rotor Options: Fixed-angle and swing-out rotors for diverse tube types (100 mL, 50 mL, 15 mL, 2.0 mL, PCR strips) .
- Motor: Maintenance-free brushless DC motor .
- Display: LCD display for speed (RPM) and Relative Centrifugal Force (RCF/xg) monitoring .
- Control: User-friendly interface with programmable memory .
- Safety Features: Door interlock, imbalance protection, over-speed detection, over-temperature detection .

2. TECHNICAL & PERFORMANCE PROPERTIES

Maximum Speed: 6,000 rpm (300 – 6,000 rpm, increment: 10 rpm) .
Maximum RCF (Relative Centrifugal Force): 4,100 × g (increment: 10 × g) .
Speed Accuracy: ±20 rpm .
Rotor Capacity (Maximum): 4 × 100 mL (swing-out rotor); 6 × 50 mL (angle rotor); 30 × 2.0 mL / 60 × 2.0 mL (angle rotor) .
Run Time: 30 seconds – 99 minutes; HOLD (continuous running) .
Program Memory Storage: 9 program storage capacity .
Acceleration/Deceleration Levels: 9 acceleration steps / 10 deceleration steps .
Motor Type: Maintenance-free brushless DC motor .
Noise Level: ≤ 65 dB .
Power Requirements: 220-240V, 50Hz/60Hz, 6.3A; 110-120V, 50Hz/60Hz,10A; 660W .
Dimensions (L × W × H): 570 × 445 × 295 mm .
Weight: 36 kg .
Certifications: CE, cTÜVus, FCC, IVD .

3. PHYSICAL & OPERATIONAL PROPERTIES

Construction: High-strength materials with excellent dynamic balancing for quiet, stable operation at high capacity .
Control: LCD display with user-friendly interface; speed/RCF switchover function; Pulse key for quick spin .
Quick Spin Function: Pulse key allows instantaneous centrifugation for quick sample processing .
Operation Modes: Timed operation (30 sec-99 min) and continuous (HOLD) operation .
Rotor Exchange: Tool-free rotor identification and easy rotor change for quick switching between applications .
Rotor Identification: Automatic rotor identification for safety and performance optimization .
Portability: Benchtop design with compact footprint suitable for routine laboratory use.
Maintenance: Brushless DC motor eliminates routine brush replacement .

4. SAFETY & COMPLIANCE ATTRIBUTES

Regulatory Status: Class II medical device for clinical diagnostic use; compliant with In Vitro Diagnostic (IVD) medical equipment requirements .
Safety Certifications: CE certified; cTÜVus certified; FCC certified .
Safety Features: Door interlock system (prevents operation with lid open), imbalance protection alarm, over-speed detection, over-temperature detection, automatic internal diagnosis system .
Electrical Safety: Over-temperature protection; wide voltage tolerance (110-240V) for international use .
Noise Control: Low noise operation (≤65 dB) for comfortable laboratory environment .
Compliance: Complies with IEC 61010-1, IEC 61010-2-020, and EN 61010-1/2-020 safety standards .

5. STORAGE & HANDLING ATTRIBUTES

Storage: Store on clean, dry benchtop; ensure adequate clearance for ventilation; ambient temperature 2–40°C, relative humidity ≤80% .
Cleaning: Wipe exterior with soft, damp cloth using neutral detergent; 70% ethanol solution may be used for sterilization; do not pour water directly into rotor chamber .
Rotor Maintenance: Remove and clean rotors with mild detergent; dry thoroughly before reinstallation; inspect rotor seal rings regularly .
Inspection: Inspect rotors for corrosion or scratches before each use; do not use damaged rotors .
Power Cord: Inspect power cord for damage before each use.
Transport: Remove rotor before moving the centrifuge .

6. LABORATORY & CLINICAL APPLICATIONS

Primary Application: High-capacity, low-speed multipurpose sample processing for blood chemistry, coagulation testing, urinalysis, nucleic acid extraction, microplate processing, and general laboratory workflows in clinical diagnostic and research settings .
Clinical Role: Essential sample preparation equipment in clinical diagnostic laboratories, hospital laboratories, physician office laboratories, blood banks, molecular diagnostics labs, research laboratories, and industrial quality control facilities.

SAFETY HANDLING PRECAUTIONS

1. SAFETY PRECAUTIONS

Rotor Balancing: Ensure rotor is balanced with tubes of equal weight; imbalance may cause excessive vibration and trigger automatic imbalance protection alarm .
Lid Security: Ensure lid is securely closed before operation; door interlock prevents operation with open lid .
Rotor Inspection: Inspect rotors for cracks, corrosion, or damage before each use; do not use damaged rotors .
Tube Compatibility: Use only tubes rated for centrifugation at maximum speed (6,000 rpm) and capacity .
Rotor Loading: Load tubes symmetrically; never run rotor with unbalanced loads .
Cleaning: Clean spills immediately; disinfect rotor chamber if biological materials are involved; do not pour water directly into rotor chamber .
Placement: Place on firm, flat, level surface; ensure the four feet stand firmly on the table; avoid vibration and airflow around the instrument .
Training: Only trained laboratory personnel should operate the centrifuge.

2. FIRST AID MEASURES

Tube Breakage: If tube breaks during operation, stop centrifuge immediately, allow rotor to stop fully, carefully remove fragments using forceps, disinfect rotor and chamber.
Sample Splash: If biological sample splashes, disinfect area immediately with appropriate disinfectant (e.g., 70% ethanol, bleach solution).
Imbalance Shutdown: If imbalance shutdown occurs, rebalance rotor equally, restart centrifuge.
Power Failure: If power fails during operation, allow rotor to stop naturally before opening lid.

3. FIRE FIGHTING MEASURES

Flammability: Plastic and electronic components may burn.
Extinguishing Media: Use carbon dioxide or dry chemical extinguisher for electrical fires.
Fire Response: Unplug centrifuge immediately; do not use water on electrical fire.
