LCD Digital Heating Magnetic Stirrer (S-H280-B500)

WhatsApp Order

The LCD Digital Heating Magnetic Stirrer (S-H280-B500) is a modular, high‑safety, programmable benchtop instrument engineered for precise, safe, and versatile medium‑volume heating and stirring in clinical diagnostics, pharmaceutical quality control, analytical chemistry, and academic research laboratories. Featuring a dedicated 500 mL beaker heating mantle precisely designed for standard 500 mL borosilicate beakers, this instrument can be configured as a dedicated 500 mL beaker heater, or run in three independent modes: full heating and stirring, detached as a standard 20‑litre magnetic stirrer on its Ø135 mm ceramic‑coated work plate, or as a ”Two‑in‑One” system where one unit heats (using the heating mantle) while a separate, independent unit stirs (using the work plate) simultaneously. The system includes the PT1000 external temperature sensor, support rod, support clamp and magnetic stirring bar.

Every LCD Digital Heating Magnetic Stirrer (S-H280-B500) features a high‑resolution LCD display showing set and actual values for temperature, speed and timer; a maintenance‑free, spark‑free brushless DC motor; and an alumina‑fibre heating mantle with aluminium‑silicate (ceramic) wool insulation for uniform heat distribution and a long service life. The instrument includes the PT1000 external temperature sensor (±0.2 °C accuracy) for precise control of the actual sample liquid temperature, and a built‑in temperature self‑calibration function that further enhances accuracy for demanding applications.

Key user‑focused features for medium‑volume applications include interchangeable heating mantles for 100 mL, 250 mL, 500 mL and 1000 mL round‑bottom flasks (F series) and flat‑bottom beakers (B series), arbitrarily interchangeable; true ”Two‑in‑One” independent operation; and a compact 3.7 kg footprint (295 × 160 mm).

Safety is exemplary with TÜV certification (CE, cTUVus, FCC), two independent safety circuits providing redundant over‑temperature protection (420 °C hardware cutoff), an independent residual heat warning indicator (“HOT” flashes at >50 °C and continues even after the unit is turned off, including unplugged, until the mantle is safe to touch), and IP21‑rated housing with a fire‑resistant metal outer shell.

For the clinical laboratory scientist, trace element analyst, and pharmaceutical QC chemist, the MS‑H280‑B500 delivers the modular versatility, medium‑batch processing capacity, and high safety required for sample digestion for trace element analysis (blood lead, urine cadmium, heavy metals), medium‑volume organic synthesis, dissolution testing and solid‑liquid extraction. For the patient, the reliable performance of this instrument ensures that diagnostic tests and pharmaceutical products are accurate, reproducible and processed efficiently, directly supporting effective clinical decision‑making, appropriate treatment selection, and patient safety.

Compare

Add to wishlist

Description

LCD Digital Heating Magnetic Stirrer (S-H280-B500)

PRIMARY CLINICAL & DIAGNOSTIC USES

1. Large‑Volume, Uniform Heating for 500 mL Beaker Preparations
Primary Use: Provides a programmable LCD digital heating magnetic stirrer with a dedicated 500 mL beaker heating mantle (inner diameter 72.75 mm to 89.75 mm depending on manufacturer source – always check the vessel size compatibility supplied as the ‘B500’ heating sleeve), used for the controlled, uniform heating and simultaneous stirring of medium‑large volume clinical samples, reagents, and biological specimens in clinical diagnostics, pharmaceutical research, and analytical laboratories. The system features a maximum stirring capacity of 20 L (water) on its Ø135 mm ceramic‑coated aluminium work plate (when the mantle is detached), a speed range of 200 to 1500 rpm (±20 rpm accuracy), and a heating temperature range from 25 °C to 280 °C in 1 °C increments [6†L14-L15][8†L22-L23]. The high‑resolution LCD digital display simultaneously shows set and actual values for temperature, stirring speed, and timer status.

How it helps: For the clinical chemist and pharmaceutical research scientist, the precisely contoured 500 mL beaker heating mantle ensures maximum surface‑to‑vessel contact, eliminating localised hot spots that could degrade heat‑sensitive clinical reagents. The intelligent interchangeable heating sleeve design allows flexible configuration with 100 mL, 250 mL, 500 mL, and 1000 mL round‑bottom flasks, as well as 100 mL, 250 mL, 500 mL, and 1000 mL flat‑bottom beakers, which can be interchanged arbitrarily [6†L7-L8][7†L7-L9]. The unit can also be run as two independent devices – one heating (using the mantle) and one stirring (using the work plate) – simultaneously , dramatically improving instrument utilisation in lean diagnostic laboratories [6†L8-L9][9†L8-L9]. For the patient receiving cell‑based therapies or pharmaceutical formulations, the reproducibility and thermal uniformity of the platform ensure consistent conditions for critical diagnostic sample preparation, supporting accurate test results and the safe development of new compounds.

2. Trace Element Digestion and Medium‑Volume Sample Preparation
Primary Use: Used for the controlled digestion of patient serum, whole blood, urine, and tissue homogenates in strong acids at temperatures up to 280 °C, prior to trace element analysis by atomic absorption spectroscopy (AAS) or inductively coupled plasma mass spectrometry (ICP‑MS) [6†L14-L15]. The built‑in temperature self‑calibration function and PT1000 external temperature sensor port (±0.2 °C accuracy) enable precise closed‑loop control of the actual sample temperature [6†L15][8†L13-L14][10†L15-L16]. Power consumption of the heating mantle is 380 W (when operating on a 200‑240 V circuit) [6†L16-L18].

How it helps: For the trace element analyst processing medium‑volume patient samples in toxicology and occupational health screening, the 500 mL capacity supports the simultaneous digestion of 4‑6 individual samples or one large‑volume specimen in a single run, reducing total preparation time. The PT1000 external temperature sensor enables the instrument to regulate the actual temperature of the acid digest directly (±0.2 °C accuracy), ensuring complete, uniform oxidation of organic matrices even in demanding trace element analysis applications [6†L15][8†L13-L14][10†L15-L16]. The built‑in temperature self‑calibration function (customer‑accessible) and two independent safety circuits continuously monitor system status; if a sensor failure, over‑temperature (>420 °C), or short circuit is detected, the device stops heating, displays an error code, and cuts off power [6†L12-L13][9†L13-L14]. For the patient undergoing heavy metal screening (e.g., lead, mercury, cadmium) or nutritional deficiency monitoring (zinc, copper, selenium), the accurate, medium‑volume digestion achieved with the MS‑H280‑B500 results in precise and reliable clinical measurements, free from matrix interference, directly supporting correct diagnosis and treatment.

3. Benchtop Gel Melting and Culture Media Preparation for Medium‑Volume Batch Workflows
Primary Use: Enables safe, uniform heating and melting of solid or semi‑solid culture media, nutrient agars, agarose gels, and heat‑pourable gels (e.g., polyacrylamide) directly in 500 mL beakers, as well as the preparation of temperature‑sensitive standard solutions and buffers for medium‑batch molecular diagnostics and clinical microbiology workflows. The heating mantle securely holds the vessel, allowing the top half to remain visible for easy monitoring of liquid level, clarity, and dissolved solids during operation.

How it helps: For the clinical molecular biologist and microbiology technologist processing medium volumes of patient samples in standard batch sizes, the 500 mL mantle capacity supports the preparation of 40‑50 culture plates per batch, with homogeneous media distribution and low batch‑to‑batch variability. The glass‑fibre inner sleeve with high‑quality aluminium‑silicate wool provides superior heat retention and 500 °C thermal resistance, allowing solid media to melt evenly without localised scorching that could degrade heat‑sensitive nutrients [6†L15]. The aluminium‑structure heating mantle with a corrosion‑resistant powder‑coated outer shell resists chemical attack from acidic media components (pH down to 4) and alkaline solutions, including biological buffers and hot SDS solutions . The high‑performance alumina silicate fibre sleeve ensures precise temperature control, uniform heating, and corrosion resistance, guaranteeing that solid residues such as nutrient powders are completely dissolved. For the patient, correctly prepared, homogeneous media in batch volume ensures that bacterial identification and molecular diagnostic testing for infectious diseases are accurate, reproducible, and reflect low batch‑to‑batch variability across patient specimens.

4. Dual‑Mode Versatility for Pharmaceutical Quality Control and Industrial‑Scale R&D
Primary Use: The instrument can be used in three independent configurations: as a complete heating and stirring unit (when the mantle is attached for 500 mL beaker work), as a stirring‑only unit on its 20‑litre capacity ceramic‑coated work plate (when the mantle is detached), or as a dual‑purpose system where one unit heats (using the mantle) while a separate, independent unit stirs (using the work plate) simultaneously [6†L8-L9][9†L8-L9].

How it helps: For the laboratory manager and R&D director, the ability to run a 500 mL synthesis on the heating mantle while simultaneously stirring a 5‑litre beaker of buffer on the work plate dramatically improves productivity. A single 3.7 kg instrument can process a morning’s batch of patient digests or QC standards, then be reconfigured for general stirring tasks after lunch – reducing equipment duplication and saving laboratory bench space at the end of each duty shift. For the patient, streamlined, standardised processing of QC materials means fewer procedural errors across medium‑volume sample runs, supporting faster, more accurate diagnostic test results.

SECONDARY & SUPPORTIVE USESSECON

1. General‑purpose 500 mL beaker heating for chemical and industrial applications: Provides stable, uniform heating for dissolution, digestion, and solvent processing of medium‑volume chemical and industrial samples, supporting fine chemical, petrochemical, food processing, and pharmaceutical industries (25–280 °C, 1 °C increments) [6†L7-L8][7†L16-L18][9†L22-L24].

2. Quality control dissolution testing for drug development: Heats 500 mL dissolution vessels to physiological conditions (e.g., pH 6.8 phosphate buffer, 0.1 N HCl) for preliminary tablet/capsule dissolution testing, with the PT1000 sensor (±0.2 °C) providing precise closed‑loop control of the actual liquid temperature in the 500 mL beaker [6†L15][8†L13-L14][10†L15-L16].

3. Bulk solvent evaporation and concentration for analytical chemistry: Gently evaporates organic solvents from 500 mL round‑bottom flasks or beakers to concentrate non‑volatile analytes in environmental, food safety, and pharmaceutical development workflows [6†L7-L8][7†L7-L9][9†L10-L12].

4. Heating metal blocks for bead‑based DNA extraction: The 500 mL heating mantle can accommodate large metal heating blocks for 24‑48 test tubes, 0.2 mL PCR vials, 1.5 mL microcentrifuge tubes, and deep‑well plates, supporting bead‑based DNA extraction protocols and metal‑bath incubations for medium‑throughput extraction of 96‑well plates.

5. Protein denaturation and enzyme inactivation for biochemistry: Heats protein solutions in a 500 mL flask to temperatures above 70 °C to completely denature enzymes and coagulate proteins, stopping enzymatic reactions before downstream analysis in protein purification and enzyme assay workflows – conserving precious protein samples while providing full denaturation.

6. General‑purpose 500 mL heating for sample preparation in mining and environmental labs: Prepares large solid environmental samples – such as soils, sediments, and ores – by acid‑digesting or ashing 500 mL volumes prior to atomic absorption analysis. The 500 mL beaker is the industry‑standard vessel for routine sample preparation in mining and effluent testing laboratories before ICP‑MS multi‑element analysis [6†L7-L8][7†L16-L18][9†L22-L24].

7. Education and teaching laboratory heating: Serves as a versatile, user‑friendly teaching tool for university chemistry, clinical laboratory science, and pharmaceutical laboratory courses, demonstrating the principles of heating, temperature control (1 °C increments), and preparation of the chemical solution using digital controls, with a compact 3.7 kg benchtop design [6†L17-L18][7†L34-L36].

KEY PRODUCT FEATURES

1.BASIC IDENTIFICATION ATTRIBUTES

Device Type: A modular, programmable LCD digital heating magnetic stirrer with an interchangeable 500 mL beaker heating mantle.
Designation: MS‑H280‑B500 LCD Digital Heating Magnetic Stirrer; LCD Digital Magnetic Stirrer with Electric Heating Mantle (S‑H280‑B500).
Catalog Number: 8017413100 [6†L4-L6].
Key Components:
- Interchangeable 500 mL beaker heating mantle (precision inner diameter)
- Glass‑fibre inner sleeve with high‑quality aluminium‑silicate (ceramic) wool
- Aluminium‑structure heating mantle outer shell with powder‑coated, corrosion‑resistant finish
- Fire‑resistant metal outer housing (防火金属外壳) [6†L10][7†L15-L16][9†L12-L13]
- Ø135 mm ceramic‑coated aluminium work plate (when mantle is detached) [8†L20-L21][10†L13-L14]
- Maintenance‑free, spark‑free brushless DC motor (防爆直流无刷电机) [6†L11][7†L16-L17][9†L12-L13]
- High‑resolution LCD display showing set and actual values for speed, temperature, and timer [6†L14][7†L27-L30]
- PT1000 external temperature sensor port (sensor included) (±0.2 °C control accuracy) [6†L15][8†L13-L14][10†L15-L16]
- Built‑in temperature self‑calibration function (customer‑accessible) [6†L9-L10][8†L13-L14][9†L11-L12]
- Programmable timer [6†L16][9†L14-L15]
- Safety lock to prevent accidental changes to operating status
- Two independent over‑temperature safety circuits (contact‑cutoff) [6†L12-L13][7†L20-L24][9†L13-L14]
- Independent “HOT” residual heat indicator (flashes when plate >50 °C, even after power off) [6†L12-L13][7†L18-L20][9†L13-L14]
- IP21‑rated housing (protection against solids >12.5 mm and vertically falling water drops) [6†L16][7†L33-L34][9†L19-L20]

2.TECHNICAL & PERFORMANCE PROPERTIES

Heating mantle capacity (B500 variant): 500 mL beakers .
Mantle inner diameter (as supplied with B500): Precision‑contoured for optimal thermal contact with standard 500 mL beakers .
Mantle insulation material: High‑quality aluminium‑silicate (ceramic) wool / alumina fibre sleeve, providing uniform heat distribution and corrosion resistance .
Work plate material (when mantle detached): Ceramic‑coated aluminium [8†L20-L21][10†L12-L14] .
Work plate dimensions (when mantle detached): Ø135 mm (5 inches) [8†L20-L21][10†L12-L14] .
Maximum stirring capacity (H₂O) on work plate: 20 L [8†L22-L23][10†L10-L12] .
Speed range: 200–1500 rpm [6†L14][7†L27-L28][9†L15-L16] .
Speed accuracy: ±20 rpm [7†L28-L29][9†L16-L17] .
Speed display resolution: LCD [6†L14][7†L27-L28] .
Heating temperature range: 25 °C to 280 °C [6†L14-L15][7†L30-L31][9†L16-L17] .
Heating temperature steps: 1 °C increments [8†L17-L18][10†L14-L15] .
Temperature display accuracy: ±0.1 °C [6†L15][7†L30-L31][9†L17-L18] .
Temperature control accuracy (plate surface): ±1 °C (<100 °C), ±1 % (>100 °C) [6†L15][7†L32-L33][9†L18-L19] .
External temperature sensor (PT1000) accuracy: ±0.2 °C [6†L15][8†L13-L14][10†L15-L16] .
Timer range: 1 minute to 99 hours 59 minutes [6†L16][9†L14-L15] .
Residual heat warning: Activates above 50 °C; “HOT” continues flashing even after unit is powered off (if still connected to mains) [6†L12-L13][7†L18-L20][9†L13-L14] .
Over‑temperature protection: 420 °C hardware cutoff [6†L15-L16][7†L32-L33][9†L17-L18] .
Over‑temperature protection (second circuit): If the first safety circuit fails and a short circuit is detected, the second safety circuit cuts off the power supply to ensure operator safety [6†L12-L13][7†L21-L24][9†L13-L14] .
Motor type: Maintenance‑free, spark‑free brushless DC motor (explosion‑proof) [6†L11][7†L16-L17][9†L12-L13] .
Motor input power: 1.8 W [6†L16-L17][7†L33-L34][8†L22-L23] .
Motor output power: 10 W [8†L22-L23][10†L12-L13] .
Heating output power (mantle): 380 W (200‑240 V) [6†L16-L18][7†L33-L34][9†L19-L20] .
Total power consumption: 440 W / 460 W (depending on source, 230 V circuit) [7†L33-L34][9†L19-L20] .
Maximum stir bar length: 80 mm [8†L22-L23][10†L12-L13] .
Maximum magnetic bar length (500 mL beaker): 50 mm .
Data interface: RS232 (included) [6†L16-L17][10†L15-L17] .
Protection class: IP21 [6†L16][7†L33-L34][9†L19-L20] .
Power requirements: 100–120 V, 60 Hz / 200‑240 V, 50 Hz (universal input, user‑selectable by region) [6†L13-L14][10†L11-L12] .
Dimensions (L × W × H): 295 × 160 × 160 mm [6†L17-L18][7†L34-L35][9†L20-L21] .
Weight: 3.7 kg [6†L18][7†L34-L35][9†L20-L21] .
Operating conditions: 5–40 °C, ≤80 % relative humidity [6†L18][10†L16-L17] .
Certifications: TÜV‑certified (CE, cTUVus, FCC); meets DIN/EN 60529 (IP code), IEC/EN 61010‑1 safety requirements for laboratory electrical equipment [10†L5-L6] .

3.PHYSICAL & OPERATIONAL PROPERTIES

Construction: Durable, fire‑resistant metal outer housing with an interchangeable heating mantle. The heating mantle is constructed from a glass‑fibre inner sleeve and high‑quality aluminium‑silicate (ceramic) wool, providing excellent thermal insulation, uniform heating, and corrosion resistance . The aluminium‑structure mantle has a powder‑coated, corrosion‑resistant outer shell for efficient heat transfer and a long service life [6†L10-L11][8†L10-L11] .
Heating mantle (B500 variant): Dedicated 500 mL beaker heating mantle, precisely contoured to maximise surface‑to‑vessel heat transfer and ensure uniform thermal contact. The glass‑fibre and aluminium‑silicate wool liner provides superior heat retention and resistance to thermal shock .
Flexible interchangeable heating sleeves (smart sleeves): The driving unit can be flexibly configured with interchangeable heating jackets for 100 mL, 250 mL, 500 mL and 1000 mL round‑bottom flasks (F series) and flat‑bottom beakers (B series), which can be interchanged arbitrarily [6†L7-L8][7†L7-L9][9†L8-L10] .
Dual‑mode operation (“Two‑in‑One” mode): The instrument can be used in three independent configurations:
- Mode 1 (Heating + Stirring on Mantle): The mantle provides simultaneous heating and stirring of the contents of the 500 mL beaker.
- Mode 2 (Stirring‑Only): The mantle can be detached, and the instrument functions as a standard 20‑litre magnetic stirrer on its Ø135 mm ceramic‑coated work plate.
- Mode 3 (Dual‑purpose Operation – Heat + Stir independently): One unit heats (using the heating mantle) while a separate, independent unit stirs (using the 20‑litre capacity work plate) . This offers genuine two‑device‑in‑one capability, dramatically improving laboratory productivity and instrument utilisation in lean diagnostic laboratories [6†L8-L9][9†L8-L9] .
Display: High‑contrast LCD digital display simultaneously shows set and actual values for temperature and speed, as well as timer status, providing complete operational visibility at a glance without toggling options [6†L14][7†L27-L30] .
Operation: Simple, intuitive digital controls with tactile buttons for temperature, speed and timer programming. Incremental 1 °C temperature adjustment and 1 rpm speed resolution allow precise setting of experimental parameters [6†L14-L15][8†L17-L18][10†L14-L15] .
Heating technology: PID‑controlled heating with advanced microprocessor control for stable, overshoot‑free temperature regulation, with or without the external PT1000 sensor. The built‑in temperature self‑calibration function (customer‑accessible) allows the user to correct for minor temperature offsets, ensuring exceptional measurement accuracy over time [6†L9-L10][8†L13-L14][9†L11-L12] .
Stirring system: Powerful rare‑earth magnets provide strong magnetic coupling, preventing stir bar decoupling even with viscous liquids or at high speeds. The brushless DC motor provides stable torque and ultra‑quiet, vibration‑free operation [6†L11][7†L16-L17][9†L12-L13] .
Safety functions:
- Two independent safety circuits: Two independent circuits continuously monitor system status. A PT1000 alert triggers in case of sensor failure; if sensor failure or over‑temperature is detected (above 420 °C), the machine reports an error and stops heating; if the first safety circuit fails and a short circuit occurs, the second safety circuit cuts off the power supply to ensure operator safety [6†L12-L13][7†L20-L24][9†L13-L14] .
- Residual heat warning (“HOT” indicator): The “HOT” safety indicator activates when the work plate exceeds 50 °C and continues flashing on the display even after the unit is turned off (including unplugged). This alerts users to the dangerously hot surface until the plate/mantle is safe to touch (temperature drops below 50 °C) [6†L12-L13][7†L18-L20][9†L13-L14] .
- 420 °C over‑temperature protection (hardware cutoff): A separate thermal cut‑off sensor shuts down heating if the work plate exceeds 420 °C, preventing runaway heating, fire hazards, and sample destruction even if the primary control system fails [6†L15-L16][7†L32-L33][9†L17-L18] .
- IP21 protection class: The IP21‑rated housing (DIN/EN 60529) provides protection against solid foreign objects >12.5 mm and vertically falling water drops (basic splash protection), ensuring reliable service in busy laboratory environments [6†L16][7†L33-L34][9†L19-L20] .
Spill protection: IP21‑rated metal housing offers protection against solid foreign objects >12.5 mm and vertically falling water drops. The fire‑resistant metal housing also provides protection against chemical spills and is easy to clean .
Portability: Compact benchtop design with a small footprint of 295 × 160 mm and weight 3.7 kg, easily moved between workstations [6†L17-L18][7†L34-L35][9†L20-L21] .
Maintenance: The brushless DC motor is maintenance‑free, requiring no routine brush replacement or lubrication. The ceramic‑coated work plate is easy to clean with a mild detergent and soft, damp cloth [6†L11][7†L16-L17][9†L12-L13] .
Included accessories: The standard package includes the PT1000 external temperature sensor, support rod, magnetic stirring bar, and support clamp .
Standards and certifications: TÜV‑certified (CE, cTUVus, FCC) [10†L5-L6] .

4.SAFETY & COMPLIANCE ATTRIBUTES

Regulatory Status: General laboratory equipment for in vitro diagnostic (IVD) use. Manufactured under ISO 9001 and ISO 13485 quality management systems. TÜV‑certified safety: CE, cTUVus, FCC ; meets DIN/EN 60529 (IP code), IEC/EN 61010‑1 safety requirements for laboratory electrical equipment [10†L5-L6] .
Two Independent Safety Circuits: Two independent safety circuits continuously monitor the device. If sensor failure or over‑temperature is detected, the machine stops heating and displays an error. If the first safety circuit fails and a short circuit is detected, the second safety circuit cuts off the power supply to ensure operator safety [6†L12-L13][7†L20-L24][9†L13-L14] .
Residual Heat Warning: The “HOT” safety indicator activates when the work plate exceeds 50 °C and continues flashing on the display even after the unit is turned off (if still connected to mains). This critical safety feature alerts users to the dangerously hot surface until the plate/mantle is cool (temperature drops below 50 °C) [6†L12-L13][7†L18-L20][9†L13-L14] .
Over‑temperature Protection (Hardware): 420 °C hardware cutoff prevents runaway heating and fire hazards, even if the primary control system fails [6†L15-L16][7†L32-L33][9†L17-L18] .
Motor Safety: Brushless, spark‑free DC motor (explosion‑proof) with maintenance‑free service and long operational life, designed for continuous laboratory use [6†L11][7†L16-L17][9†L12-L13] .
Chemical Safety: The ceramic‑coated aluminium work plate and fire‑resistant metal outer housing are resistant to strong acids, strong alkalis and organic solvents, preventing corrosion and ensuring a long service life. The alumina‑fibre inner sleeve of the heating mantle is chemically resistant and will absorb small chemical spills without short‑circuiting the heating element [6†L10-L11][8†L10-L11][9†L11-L12] .
Fire Safety: Fire‑resistant metal housing, glass‑fibre insulation, and a non‑flammable ceramic‑coated work plate provide excellent fire protection [6†L10-L11][9†L12-L13] .
Electrical Safety: Designed with a brushless, spark‑free DC motor (explosion‑proof), making the instrument safe for use in environments where flammable solvents may be present. The IP21‑rated housing offers protection against solid foreign objects >12.5 mm and vertically falling water drops [6†L11][6†L16][7†L16-L17] .
Quality Assurance: Each instrument is factory‑calibrated, and the built‑in temperature self‑calibration function may be used by the customer to adjust the internal offset for improved precision. The unit is supplied with a calibration certificate and is backed by the manufacturer’s warranty .

5.STORAGE & HANDLING ATTRIBUTES

Storage: Store the instrument in a clean, dry, dust‑free environment at room temperature (15–30 °C) when not in use. Allow the unit to cool completely (verify “HOT” indicator is off) before storage. The heating mantle should be stored in a dry, clean environment to prevent moisture ingress into the fibre insulation.
Installation: Place the instrument on a stable, level, non‑flammable, heat‑resistant laboratory benchtop away from flammable materials, volatile solvents, combustible gases, or paper products. Allow at least 10 cm clearance on all sides for heat dissipation. Do not use near water baths or sinks where splashing may occur.
Cleaning: Unplug the unit and allow it to cool completely before cleaning. Wipe the ceramic‑coated work plate, the fire‑resistant metal housing, and the outer surface of the heating mantle with a soft, damp cloth using a mild laboratory detergent or 70 % isopropyl alcohol. Do not immerse the unit in liquid. Do not use abrasive cleaners or metal‑scouring pads. Do not saturate the fibre insulation inside the heating mantle with liquid.
Pre‑use inspection: Before each use, inspect the power cord and plug for any damage. Ensure the heating mantle is free of cracks and foreign objects. Verify that the correct heating mantle size (500 mL) is fitted for the beaker being used. Check that the beaker is dry, free of cracks, and properly seated in the mantle for maximum surface contact.
Beaker selection for heating mantle: Use only standard 500 mL beakers made of borosilicate glass (e.g., Pyrex or Kimax) designed to withstand the operating temperature up to 280 °C. Do not use cracked, damaged, or non‑borosilicate glassware .
Operation with external sensor (PT1000): Insert the PT1000 temperature sensor probe into the sample vessel and secure it with the support clamp. Do not allow the sensor wire to contact the hot heating mantle, as this may melt the insulation and cause sensor failure or an electrical hazard .
Attaching and removing heating mantles: Ensure the driving unit is turned off and cool. The interchangeable mantle attaches via a dedicated connector. Fit the mantle firmly onto the work plate and lock it according to the manufacturer‘s instructions. To remove after use, allow the mantle to cool completely (“HOT” indicator off) before disconnecting .
Independent dual‑purpose operation (“two‑in‑one mode”): To run the instrument as two separate devices (one heating on the mantle, one stirring on the base work plate), follow the manufacturer’s configuration instructions in the user manual. This dual‑mode functionality dramatically increases laboratory productivity .
Temperature self‑calibration: To perform a self‑calibration, follow the manufacturer‘s procedure using a calibrated external thermometer. This adjusts the internal offset to correct for minor temperature deviations and maintain measurement accuracy over time .
Timer operation: Program the timer for the desired heating and stirring duration. When the timer reaches zero, the unit stops heating but continues stirring (if stirring was enabled), and the buzzer sounds. Press any button to silence the buzzer. The timer can also be deactivated if not needed .
Cooling down: After use, turn off the power and allow the heating mantle to cool completely until the “HOT” indicator stops flashing (typically 30–60 minutes, depending on operating temperature) before cleaning, moving, storing, or changing the mantle .
Periodic verification: Verify temperature accuracy periodically using a calibrated external thermometer. If deviation exceeds specifications (±1 °C <100 °C or ±1 % >100 °C), perform a temperature self‑calibration routine .

6.LABORATORY & CLINICAL APPLICATIONS

Primary Application: General‑purpose, medium‑volume heating and stirring for clinical diagnostics (trace element digestion for heavy metal testing – blood lead, urine cadmium, heavy metals), pharmaceutical quality control, analytical chemistry (reflux, distillation, solvent evaporation), and academic research laboratories where the ability to heat both round‑bottom flasks and flat‑bottom beakers on a single versatile platform is required .

Clinical Role: A versatile and essential benchtop instrument for hospital and clinical chemistry laboratories, toxicology departments, pharmaceutical R&D and quality control, analytical chemistry departments, environmental testing stations, food safety laboratories, and research institutions. Critical for medium‑batch sample digestion for trace element analysis, 500 mL batch sample preparation, culture media preparation (40‑50 plates per batch), and dissolution testing where precise, safe, and versatile heating with stirring is mandatory for diagnostic accuracy and patient safety .

SAFETY HANDLING PRECAUTIONS

1. SAFETY PRECAUTIONS

Magnetic Field Interference: The stirrer contains strong permanent magnets. Keep a safe distance (at least 30 cm) from pacemakers, implantable cardioverter‑defibrillators (ICDs), and other medical devices. Do not place the stirrer near sensitive electronic equipment, magnetic storage media (hard drives, credit cards, magnetic ID badges), or monitors.
Chemical Compatibility: Always verify that the ceramic‑coated work plates are compatible with the chemicals being stirred. While the coating resists strong acids, strong alkalis, and organic solvents, prolonged exposure to some concentrated reagents may cause degradation. Clean spills promptly to prevent surface damage.
Vessel and Stir Bar Selection: Use only flat‑bottomed vessels (e.g., beakers, Erlenmeyer flasks) to ensure stability on the work plates. Ensure the magnetic stir bar is in good condition without chips or cracks and is properly centered in the vessel before starting the motor. Do not exceed the maximum stir bar length of 40 mm per channel.
Start Slowly: Always start stirring at the lowest speed (200 rpm) and gradually increase to the desired speed. This prevents the stir bar from decoupling, which can cause splashing, vessel instability, or sample loss. Sudden high‑speed starts may cause the stir bar to spin erratically and strike the vessel wall.
Electrical Safety: Do not operate the instrument with wet hands. Disconnect the power cord before cleaning, servicing, or moving the unit. Use only the supplied grounded power cord and ensure the outlet provides proper grounding. Do not operate if the power cord is damaged or liquid has spilled into the housing. The IP21 rating offers basic protection only; do not immerse the unit or allow significant liquid ingress.
Spill Management: If a liquid spill occurs on any work plate during operation, turn off the power for that channel immediately. Wipe the spill after ensuring the plate is clean and dry before resuming use. Do not allow liquids to pool around the edges of the plates or to enter the housing vents.
Ventilation and Clearance: Place the instrument on a stable, level, non‑flammable benchtop with at least 10 cm clearance on all sides for adequate ventilation. Do not cover the instrument during operation. Ensure the area is free from flammable solvents, combustible gases, and paper products.
Multi‑Channel Operation: When operating multiple channels simultaneously, ensure that vessels on adjacent channels do not touch or interfere with each other. Allow sufficient spacing between vessels for safe handling and to prevent magnetic interference between channels. The 6‑channel design has pre‑determined spacing; do not place oversized vessels that exceed the channel boundaries.
Cleaning and Maintenance: Unplug the unit before cleaning. Allow any warm plates to cool to room temperature before wiping. Use only a soft, damp cloth with mild detergent or 70 % isopropyl alcohol. Do not use abrasive cleaners, metal scouring pads, or sharp objects that may scratch the ceramic coating. Do not immerse the unit or allow liquid to enter the housing.
Overheating Prevention: This is a non‑heating model, but continuous operation at maximum speed (1500 rpm) for extended periods may cause the motors to warm slightly. If any channel emits an unusual odor, excessive heat, or noise, turn off the unit immediately and disconnect power. Allow the unit to cool before inspecting for mechanical issues.
Magnetic Stir Bar Wear: Inspect stir bars regularly for signs of wear, chipping, or cracking. Worn stir bars can scratch the ceramic coating or shed particles into the sample. Replace stir bars at least annually or immediately if damage is visible.
Training Requirement: Only trained laboratory personnel with appropriate technical background in magnetic stirrer operation should operate the MS‑M‑S6 for clinical diagnostic or research applications. Users must read and understand the operator’s manual before first use.

2. FIRST AID MEASURES

Sample Splash to Eyes: If a biological or chemical sample splashes into the eyes during stirring, flush immediately with water for 15 minutes and seek medical attention.
Skin Contact with Chemical Sample: Wash contaminated skin with soap and water thoroughly for at least 5 minutes. If irritation or signs of chemical burn develop, seek medical evaluation. Refer to the Safety Data Sheet (SDS) for the specific chemical involved.
Sharps Injury (Broken Glassware): If a broken vessel punctures the skin, allow the wound to bleed freely, wash with soap and water for 15 minutes, apply antiseptic and a sterile bandage. If the vessel contained patient biological material, follow the facility’s exposure management protocol for bloodborne pathogens.
Inhalation of Chemical Vapors: If vapors from volatile reagents are inhaled during sample preparation, move to fresh air immediately. Seek medical attention if symptoms (coughing, dizziness, difficulty breathing) persist.
Electrical Shock: If an electrical shock incident occurs, disconnect power at the circuit breaker before attempting to assist the victim. Do not touch the victim until power is disconnected. Call emergency medical services immediately.

3. FIRE FIGHTING MEASURES

Flammability: The plastic components of the stirrer housing, power cord, and electronic components are combustible. Do not operate near flammable solvents, gases, or volatile materials. The primary fire hazard is the flammable liquids being stirred.
Extinguishing Media: Use carbon dioxide (CO₂) or a dry chemical extinguisher for fires involving electrical equipment. Do not use water on electrical fires.
Fire Response: In case of fire, disconnect the stirrer from its power source if safe to do so. Evacuate the area and follow the laboratory’s fire safety protocols. Do not attempt to extinguish a fire if not trained or if the fire is spreading rapidly.
Special Protective Equipment for Firefighters: Firefighters should wear self‑contained breathing apparatus (SCBA) and full structural firefighting gear when fighting fires in laboratory settings.

LCD Digital Heating Magnetic Stirrer (S-H280-B500)

LCD Digital Heating Magnetic Stirrer (S-H280-B500)

PRIMARY CLINICAL & DIAGNOSTIC USES

SECONDARY & SUPPORTIVE USESSECON

3. Bulk solvent evaporation and concentration for analytical chemistry: Gently evaporates organic solvents from 500 mL round‑bottom flasks or beakers to concentrate non‑volatile analytes in environmental, food safety, and pharmaceutical development workflows [6†L7-L8][7†L7-L9][9†L10-L12].

1.BASIC IDENTIFICATION ATTRIBUTES

Device Type: A modular, programmable LCD digital heating magnetic stirrer with an interchangeable 500 mL beaker heating mantle.

Designation: MS‑H280‑B500 LCD Digital Heating Magnetic Stirrer; LCD Digital Magnetic Stirrer with Electric Heating Mantle (S‑H280‑B500).

Catalog Number: 8017413100 [6†L4-L6].

Key Components:

Interchangeable 500 mL beaker heating mantle (precision inner diameter)

Glass‑fibre inner sleeve with high‑quality aluminium‑silicate (ceramic) wool

Aluminium‑structure heating mantle outer shell with powder‑coated, corrosion‑resistant finish

Fire‑resistant metal outer housing (防火金属外壳) [6†L10][7†L15-L16][9†L12-L13]

Ø135 mm ceramic‑coated aluminium work plate (when mantle is detached) [8†L20-L21][10†L13-L14]

Maintenance‑free, spark‑free brushless DC motor (防爆直流无刷电机) [6†L11][7†L16-L17][9†L12-L13]

High‑resolution LCD display showing set and actual values for speed, temperature, and timer [6†L14][7†L27-L30]

PT1000 external temperature sensor port (sensor included) (±0.2 °C control accuracy) [6†L15][8†L13-L14][10†L15-L16]

Built‑in temperature self‑calibration function (customer‑accessible) [6†L9-L10][8†L13-L14][9†L11-L12]

Programmable timer [6†L16][9†L14-L15]

Safety lock to prevent accidental changes to operating status

Two independent over‑temperature safety circuits (contact‑cutoff) [6†L12-L13][7†L20-L24][9†L13-L14]

Independent “HOT” residual heat indicator (flashes when plate >50 °C, even after power off) [6†L12-L13][7†L18-L20][9†L13-L14]

IP21‑rated housing (protection against solids >12.5 mm and vertically falling water drops) [6†L16][7†L33-L34][9†L19-L20]

2.TECHNICAL & PERFORMANCE PROPERTIES

Heating mantle capacity (B500 variant): 500 mL beakers .

Mantle inner diameter (as supplied with B500): Precision‑contoured for optimal thermal contact with standard 500 mL beakers .

Mantle insulation material: High‑quality aluminium‑silicate (ceramic) wool / alumina fibre sleeve, providing uniform heat distribution and corrosion resistance .

Work plate material (when mantle detached): Ceramic‑coated aluminium [8†L20-L21][10†L12-L14] .

Work plate dimensions (when mantle detached): Ø135 mm (5 inches) [8†L20-L21][10†L12-L14] .

Maximum stirring capacity (H₂O) on work plate: 20 L [8†L22-L23][10†L10-L12] .

Speed range: 200–1500 rpm [6†L14][7†L27-L28][9†L15-L16] .

Speed accuracy: ±20 rpm [7†L28-L29][9†L16-L17] .

Speed display resolution: LCD [6†L14][7†L27-L28] .

Heating temperature range: 25 °C to 280 °C [6†L14-L15][7†L30-L31][9†L16-L17] .

Heating temperature steps: 1 °C increments [8†L17-L18][10†L14-L15] .

Temperature display accuracy: ±0.1 °C [6†L15][7†L30-L31][9†L17-L18] .

Temperature control accuracy (plate surface): ±1 °C (<100 °C), ±1 % (>100 °C) [6†L15][7†L32-L33][9†L18-L19] .

External temperature sensor (PT1000) accuracy: ±0.2 °C [6†L15][8†L13-L14][10†L15-L16] .

Timer range: 1 minute to 99 hours 59 minutes [6†L16][9†L14-L15] .

Residual heat warning: Activates above 50 °C; “HOT” continues flashing even after unit is powered off (if still connected to mains) [6†L12-L13][7†L18-L20][9†L13-L14] .

Over‑temperature protection: 420 °C hardware cutoff [6†L15-L16][7†L32-L33][9†L17-L18] .

Over‑temperature protection (second circuit): If the first safety circuit fails and a short circuit is detected, the second safety circuit cuts off the power supply to ensure operator safety [6†L12-L13][7†L21-L24][9†L13-L14] .

Motor type: Maintenance‑free, spark‑free brushless DC motor (explosion‑proof) [6†L11][7†L16-L17][9†L12-L13] .

Motor input power: 1.8 W [6†L16-L17][7†L33-L34][8†L22-L23] .

Motor output power: 10 W [8†L22-L23][10†L12-L13] .

Heating output power (mantle): 380 W (200‑240 V) [6†L16-L18][7†L33-L34][9†L19-L20] .

Total power consumption: 440 W / 460 W (depending on source, 230 V circuit) [7†L33-L34][9†L19-L20] .

Maximum stir bar length: 80 mm [8†L22-L23][10†L12-L13] .

Maximum magnetic bar length (500 mL beaker): 50 mm .

Data interface: RS232 (included) [6†L16-L17][10†L15-L17] .

Protection class: IP21 [6†L16][7†L33-L34][9†L19-L20] .

Power requirements: 100–120 V, 60 Hz / 200‑240 V, 50 Hz (universal input, user‑selectable by region) [6†L13-L14][10†L11-L12] .

Dimensions (L × W × H): 295 × 160 × 160 mm [6†L17-L18][7†L34-L35][9†L20-L21] .

Weight: 3.7 kg [6†L18][7†L34-L35][9†L20-L21] .

Operating conditions: 5–40 °C, ≤80 % relative humidity [6†L18][10†L16-L17] .

Certifications: TÜV‑certified (CE, cTUVus, FCC); meets DIN/EN 60529 (IP code), IEC/EN 61010‑1 safety requirements for laboratory electrical equipment [10†L5-L6] .

3.PHYSICAL & OPERATIONAL PROPERTIES

Heating mantle (B500 variant): Dedicated 500 mL beaker heating mantle, precisely contoured to maximise surface‑to‑vessel heat transfer and ensure uniform thermal contact. The glass‑fibre and aluminium‑silicate wool liner provides superior heat retention and resistance to thermal shock .

Dual‑mode operation (“Two‑in‑One” mode): The instrument can be used in three independent configurations:

Mode 1 (Heating + Stirring on Mantle): The mantle provides simultaneous heating and stirring of the contents of the 500 mL beaker.

Mode 2 (Stirring‑Only): The mantle can be detached, and the instrument functions as a standard 20‑litre magnetic stirrer on its Ø135 mm ceramic‑coated work plate.

Display: High‑contrast LCD digital display simultaneously shows set and actual values for temperature and speed, as well as timer status, providing complete operational visibility at a glance without toggling options [6†L14][7†L27-L30] .

Operation: Simple, intuitive digital controls with tactile buttons for temperature, speed and timer programming. Incremental 1 °C temperature adjustment and 1 rpm speed resolution allow precise setting of experimental parameters [6†L14-L15][8†L17-L18][10†L14-L15] .

Stirring system: Powerful rare‑earth magnets provide strong magnetic coupling, preventing stir bar decoupling even with viscous liquids or at high speeds. The brushless DC motor provides stable torque and ultra‑quiet, vibration‑free operation [6†L11][7†L16-L17][9†L12-L13] .

Safety functions:

420 °C over‑temperature protection (hardware cutoff): A separate thermal cut‑off sensor shuts down heating if the work plate exceeds 420 °C, preventing runaway heating, fire hazards, and sample destruction even if the primary control system fails [6†L15-L16][7†L32-L33][9†L17-L18] .

IP21 protection class: The IP21‑rated housing (DIN/EN 60529) provides protection against solid foreign objects >12.5 mm and vertically falling water drops (basic splash protection), ensuring reliable service in busy laboratory environments [6†L16][7†L33-L34][9†L19-L20] .

Spill protection: IP21‑rated metal housing offers protection against solid foreign objects >12.5 mm and vertically falling water drops. The fire‑resistant metal housing also provides protection against chemical spills and is easy to clean .

Portability: Compact benchtop design with a small footprint of 295 × 160 mm and weight 3.7 kg, easily moved between workstations [6†L17-L18][7†L34-L35][9†L20-L21] .

Maintenance: The brushless DC motor is maintenance‑free, requiring no routine brush replacement or lubrication. The ceramic‑coated work plate is easy to clean with a mild detergent and soft, damp cloth [6†L11][7†L16-L17][9†L12-L13] .

Included accessories: The standard package includes the PT1000 external temperature sensor, support rod, magnetic stirring bar, and support clamp .

Standards and certifications: TÜV‑certified (CE, cTUVus, FCC) [10†L5-L6] .

4.SAFETY & COMPLIANCE ATTRIBUTES

Over‑temperature Protection (Hardware): 420 °C hardware cutoff prevents runaway heating and fire hazards, even if the primary control system fails [6†L15-L16][7†L32-L33][9†L17-L18] .

Motor Safety: Brushless, spark‑free DC motor (explosion‑proof) with maintenance‑free service and long operational life, designed for continuous laboratory use [6†L11][7†L16-L17][9†L12-L13] .

Fire Safety: Fire‑resistant metal housing, glass‑fibre insulation, and a non‑flammable ceramic‑coated work plate provide excellent fire protection [6†L10-L11][9†L12-L13] .

5.STORAGE & HANDLING ATTRIBUTES

Beaker selection for heating mantle: Use only standard 500 mL beakers made of borosilicate glass (e.g., Pyrex or Kimax) designed to withstand the operating temperature up to 280 °C. Do not use cracked, damaged, or non‑borosilicate glassware .

Operation with external sensor (PT1000): Insert the PT1000 temperature sensor probe into the sample vessel and secure it with the support clamp. Do not allow the sensor wire to contact the hot heating mantle, as this may melt the insulation and cause sensor failure or an electrical hazard .

Device Type: A modular, programmable LCD digital heating magnetic stirrer with an interchangeable 500 mL beaker heating mantle.

Interchangeable 500 mL beaker heating mantle (precision inner diameter)

Ø135 mm ceramic‑coated aluminium work plate (when mantle is detached) [8†L20-L21][10†L13-L14]

PT1000 external temperature sensor port (sensor included) (±0.2 °C control accuracy) [6†L15][8†L13-L14][10†L15-L16]

Independent “HOT” residual heat indicator (flashes when plate >50 °C, even after power off) [6†L12-L13][7†L18-L20][9†L13-L14]

IP21‑rated housing (protection against solids >12.5 mm and vertically falling water drops) [6†L16][7†L33-L34][9†L19-L20]

Heating mantle capacity (B500 variant): 500 mL beakers .

Mantle inner diameter (as supplied with B500): Precision‑contoured for optimal thermal contact with standard 500 mL beakers .

Work plate dimensions (when mantle detached): Ø135 mm (5 inches) [8†L20-L21][10†L12-L14] .

Maximum stirring capacity (H₂O) on work plate: 20 L [8†L22-L23][10†L10-L12] .

Speed range: 200–1500 rpm [6†L14][7†L27-L28][9†L15-L16] .

Speed accuracy: ±20 rpm [7†L28-L29][9†L16-L17] .

Heating temperature range: 25 °C to 280 °C [6†L14-L15][7†L30-L31][9†L16-L17] .

Heating temperature steps: 1 °C increments [8†L17-L18][10†L14-L15] .

Temperature display accuracy: ±0.1 °C [6†L15][7†L30-L31][9†L17-L18] .

Temperature control accuracy (plate surface): ±1 °C (<100 °C), ±1 % (>100 °C) [6†L15][7†L32-L33][9†L18-L19] .

External temperature sensor (PT1000) accuracy: ±0.2 °C [6†L15][8†L13-L14][10†L15-L16] .

Timer range: 1 minute to 99 hours 59 minutes [6†L16][9†L14-L15] .

Residual heat warning: Activates above 50 °C; “HOT” continues flashing even after unit is powered off (if still connected to mains) [6†L12-L13][7†L18-L20][9†L13-L14] .

Over‑temperature protection: 420 °C hardware cutoff [6†L15-L16][7†L32-L33][9†L17-L18] .

Motor input power: 1.8 W [6†L16-L17][7†L33-L34][8†L22-L23] .

Motor output power: 10 W [8†L22-L23][10†L12-L13] .

Heating output power (mantle): 380 W (200‑240 V) [6†L16-L18][7†L33-L34][9†L19-L20] .

Total power consumption: 440 W / 460 W (depending on source, 230 V circuit) [7†L33-L34][9†L19-L20] .

Maximum stir bar length: 80 mm [8†L22-L23][10†L12-L13] .

Maximum magnetic bar length (500 mL beaker): 50 mm .

Power requirements: 100–120 V, 60 Hz / 200‑240 V, 50 Hz (universal input, user‑selectable by region) [6†L13-L14][10†L11-L12] .

Dimensions (L × W × H): 295 × 160 × 160 mm [6†L17-L18][7†L34-L35][9†L20-L21] .

Weight: 3.7 kg [6†L18][7†L34-L35][9†L20-L21] .

Operating conditions: 5–40 °C, ≤80 % relative humidity [6†L18][10†L16-L17] .

Certifications: TÜV‑certified (CE, cTUVus, FCC); meets DIN/EN 60529 (IP code), IEC/EN 61010‑1 safety requirements for laboratory electrical equipment [10†L5-L6] .

Heating mantle (B500 variant): Dedicated 500 mL beaker heating mantle, precisely contoured to maximise surface‑to‑vessel heat transfer and ensure uniform thermal contact. The glass‑fibre and aluminium‑silicate wool liner provides superior heat retention and resistance to thermal shock .

Mode 1 (Heating + Stirring on Mantle): The mantle provides simultaneous heating and stirring of the contents of the 500 mL beaker.

Mode 2 (Stirring‑Only): The mantle can be detached, and the instrument functions as a standard 20‑litre magnetic stirrer on its Ø135 mm ceramic‑coated work plate.

Operation: Simple, intuitive digital controls with tactile buttons for temperature, speed and timer programming. Incremental 1 °C temperature adjustment and 1 rpm speed resolution allow precise setting of experimental parameters [6†L14-L15][8†L17-L18][10†L14-L15] .

420 °C over‑temperature protection (hardware cutoff): A separate thermal cut‑off sensor shuts down heating if the work plate exceeds 420 °C, preventing runaway heating, fire hazards, and sample destruction even if the primary control system fails [6†L15-L16][7†L32-L33][9†L17-L18] .

IP21 protection class: The IP21‑rated housing (DIN/EN 60529) provides protection against solid foreign objects >12.5 mm and vertically falling water drops (basic splash protection), ensuring reliable service in busy laboratory environments [6†L16][7†L33-L34][9†L19-L20] .

Spill protection: IP21‑rated metal housing offers protection against solid foreign objects >12.5 mm and vertically falling water drops. The fire‑resistant metal housing also provides protection against chemical spills and is easy to clean .

Portability: Compact benchtop design with a small footprint of 295 × 160 mm and weight 3.7 kg, easily moved between workstations [6†L17-L18][7†L34-L35][9†L20-L21] .

Over‑temperature Protection (Hardware): 420 °C hardware cutoff prevents runaway heating and fire hazards, even if the primary control system fails [6†L15-L16][7†L32-L33][9†L17-L18] .

Beaker selection for heating mantle: Use only standard 500 mL beakers made of borosilicate glass (e.g., Pyrex or Kimax) designed to withstand the operating temperature up to 280 °C. Do not use cracked, damaged, or non‑borosilicate glassware .

Cooling down: After use, turn off the power and allow the heating mantle to cool completely until the “HOT” indicator stops flashing (typically 30–60 minutes, depending on operating temperature) before cleaning, moving, storing, or changing the mantle .

Periodic verification: Verify temperature accuracy periodically using a calibrated external thermometer. If deviation exceeds specifications (±1 °C <100 °C or ±1 % >100 °C), perform a temperature self‑calibration routine .

Ventilation and Clearance: Place the instrument on a stable, level, non‑flammable benchtop with at least 10 cm clearance on all sides for adequate ventilation. Do not cover the instrument during operation. Ensure the area is free from flammable solvents, combustible gases, and paper products.

Sample Splash to Eyes: If a biological or chemical sample splashes into the eyes during stirring, flush immediately with water for 15 minutes and seek medical attention.

Skin Contact with Chemical Sample: Wash contaminated skin with soap and water thoroughly for at least 5 minutes. If irritation or signs of chemical burn develop, seek medical evaluation. Refer to the Safety Data Sheet (SDS) for the specific chemical involved.
