The Gene Amplification Instrument (TC2000-G1) is a 96-well gradient thermal cycler featuring advanced Peltier heating/cooling technology (5°C/sec ramp rate), precise temperature control (±0.1°C accuracy), excellent temperature uniformity (±0.2°C at 55°C), edge temperature compensation, 10.1-inch LCD color touchscreen (1280×800), gradient capability (1-42°C span), Touchdown PCR support (-10°C to +10°C), Long PCR support (-600 sec to +600 sec), power failure protection, Wi-Fi connectivity, email notification, and three-level user permission management with password protection, designed for DNA amplification in clinical diagnostic, molecular biology, and research laboratories .
Key features include a 96-well aluminum block compatible with PCR tubes, 8-strips, and 96-well PCR plates (no skirt, half-skirt, full-skirt), self-adaptive pressure lever hot cap with one-step lid closure (30-115°C), 10.1-inch touchscreen with visual countdown circle display for real-time run progress, automatic self-test at power-up, standard and fast temperature control modes, program suspension and skip-to-next-step functions, USB 2.0 and built-in Wi-Fi interfaces, email notification upon run completion, run record and abnormal event logging, and USB-based software updates .
The Gene Amplification Instrument(TC2000-G1) supports standard PCR, Touchdown PCR (-10°C to +10°C) for enhanced specificity, and Long PCR (-600 sec to +600 sec) for large fragment amplification . Edge temperature compensation technology minimizes "edge effect" and ensures consistent amplification across all 96 wells . The self-adaptive pressure lever hot cap adapts to different PCR tube heights with one-step closure . Power failure protection automatically resumes unfinished cycles upon power restoration, ensuring sample safety during extended runs .
Three-level user permission management (guest, account authentication, administrator) with password protection ensures data security and regulatory compliance . The built-in Wi-Fi module allows simultaneous control of multiple PCR instruments from one computer via LAN, with email notifications sent upon run completion . The 10.1-inch touchscreen provides intuitive program editing with up to 199 cycles and 30 steps per program, and storage for over 20,000 programs via USB flash drive .
For the clinical laboratory scientist and molecular biologist, the Gene Amplification Instrument supports infectious disease detection (COVID-19, HIV, hepatitis B/C, tuberculosis, HPV, influenza), genetic mutation screening (β-thalassemia, BRCA, CFTR), viral load monitoring, gene cloning, DNA sequencing preparation, forensic DNA analysis (STR amplification), food safety pathogen detection and GMO screening, and Touchdown/Long PCR applications .
Universal voltage (100-240V, 50/60Hz) enables use in laboratories worldwide without voltage conversion, while the compact footprint (422 × 310 × 264 mm) and moderate weight (11 kg) allow easy benchtop placement . The 0-105°C temperature range, 5°C/sec ramp rate, and Peltier lifespan of up to 200,000 cycles provide rapid, reliable thermal cycling for routine and advanced diagnostic applications .
For the patient undergoing infectious disease testing, genetic screening for hereditary disorders, or viral load monitoring for chronic infections, the Gene Amplification Instrument precise temperature control, gradient optimization capability, rapid ramp rate, and data security features ensure accurate, reproducible PCR results that guide appropriate treatment decisions across clinical infectious disease, oncology, genetics, and molecular diagnostics applications .
